| A type | B type | |||||||||||
| Item/Model / | Unit | UTHS10V | UTHS15V | UTHS20V | UTHS25V | UTHS30V | UTHS10V | UTHS15V | UTHS20V | UTHS25V | UTHS30V | |
| Suit Excavator | T | 6-9 | 15 | 18-24 | 35 | 45 | 6-9 | 15 | 18-24 | 35 | 45 | |
| Weight | kg | 1250 | 1580 | 2100 | 2750 | 5350 | 1320 | 1640 | 2250 | 2920 | 5160 | |
| Opening | mm | 750 | 890 | 980 | 1100 | 1400 | 480 | 550 | 620 | 750 | 860 | |
| Blade length | mm | 140 | 160 | 200 | 240 | 300 | 130x4/320x2 | 150x4/360x2 | 170x4/380x2 | 200x4/450x2 | 200x5/600x2 | |
| Height | mm | 1620 | 2100 | 2280 | 2450 | 2850 | 1720 | 2180 | 2450 | 2850 | 3240 | |
| Width | mm | 1120 | 1280 | 1450 | 1720 | 2350 | 980 | 1040 | 1250 | 1580 | 2060 | |
| Crushing force | ton | 45 | 58 | 70 | 85 | 95 | 25 | 32 | 40 | 55 | 65 | |
| Cutting force B | ton | 90 | 115 | 130 | 165 | 260 | 45 | 50 | 65 | 80 | 100 | |
| Rated pressure | bar | 300 | 320 | 320 | 320 | 320 | 300 | 320 | 320 | 320 | 320 | |
| Rated flow | lpm | 180 | 230 | 240 | 260 | 380 | 180 | 230 | 240 | 260 | 380 | |
| Rated pressure | bar | 260 | 280 | 300 | 300 | 300 | 260 | 280 | 300 | 300 | 300 | |
| Cycle Time | Open | sec | 1.8 | 2.1 | 2.9 | 3.4 | 4.3 | 1.8 | 2.1 | 2.9 | 3.4 | 4.3 |
| Close | sec | 1.7 | 2.3 | 2.7 | 4.1 | 5.5 | 1.7 | 2.3 | 2.7 | 4.1 | 5.5 | |
